Home > products > Excavator Coupling > YN30P01002F2 Excavator Coupling fix Kobelco Excavator SK200-6

YN30P01002F2 Excavator Coupling fix Kobelco Excavator SK200-6

Category:
Excavator Coupling
Price:
USD 15~20
Payment Method:
T/T, Western Union
Specifications
Description:
Coupling
Part Number:
YN30P01002F2
Used For:
Excavators
Machine Model:
SK200-6
Performance:
Power Transmission
Appliion:
Engine Flywheel Mounted Hyd. Pump
High Light:

rubber couplings

,

shaft coupling

Introduction

YN30P01002F2 Excavator Coupling fix Kobelco Excavator SK200-6


Product Descrition:

  • Place of Origin: Guangdong, China (Mainland)

  • Brand Name: Y&F

  • Model Number: Centaflex YN30P01002F2

  • Material: DuPont Hytrel

  • Sales type: Retail, Wholesale

  • Mark: According to customer needs

  • Appliion: Construction machinery, ships, generators, compressors

  • Quality: Controlstrict 100% test

  • Mass production: Booking

  • Available: In stock

Y&F manufactures flexible couplings, rubber and various other transmission products. This elastomer torsional coupling base element replaces the base element on Lovejoy LF series / Mkipulley Centaflex CF series torsional coupling assemblies. It is made of high temperature rubber (HTR) for transferring and absorbing shock load and reducing wear on both shafts.

YN30P01002F2 Excavator Coupling fix Kobelco Excavator SK200-6







Our high quality material:



       1>Mkipulley Centaflex CF-A Series-----Natural Rubber(NR), High Temperature Rubber (HTR)

       2>Mkipulley Centaflex CF-H Series-----HTR, Hytrel

       3>Lovejoy LF series-----------------------NR, HTR, Hytrel

YN30P01002F2 Excavator Coupling fix Kobelco Excavator SK200-6

Specifiions

      *Widely used in construction machines

      *Made of natural rubber, no unbearable smell
      *Over 25 years of industry experience

Assembly (When Using CENTA-LOCK)

(1) Press the spring pin into the cylindrical hub (except for coupling size 008), and then lock aluminum insert R into the cylindrical hub.

(2) Mount the cylindrical hub (clamping hub) onto the spline shaft, and then tighten the clamping screw to lock.

(3) a. Coupling sizes 008 and 016 Lock the bushing onto the flange hub (flywheel side). Push the element into the cylindrical hub.

b. Coupling sizes 030, 040, 050, 090, 110, 160, and 240 Press the spring pin into the flange hub (flywheel side), add aluminum insert A to the element, and then lock it to the flange hub (flywheel side).



         YN30P01002F2 Excavator Coupling fix Kobelco Excavator SK200-6

Product Features:

· For use with Lovejoy LF Series Torsional coupling assemblies (sold separately)

· High temperature rubber (HTR) for transferring and absorbing shock load

· Electrical isolating to prevent electrical arcing and circuit shortages

· Attaches to flanged hub, flywheel adapter plate, or flywheel on engine side and cylindrical hub on driven equipment side

· Flexes up to 3 degrees to compensate for angular misalignment of coupled shafts

Packaging & Shipping:



Packaging: Customized packing provided
Shipping: Port:Guangzhou
Delivery time: 1-2 days after received the payment



Send RFQ
Stock:
MOQ:
5 SETS
