Centaflex-A series Coupling Hydraulic Pump Parts Rubber Coupling 4464407
Centaflex-A series Coupling Hydraulic Pump Parts Rubber Coupling 4464407
Description :
|
Brand Name |
YNF/Y&F |
|
Centaflex |
A/AS-Series |
|
Coupling egory |
Rotary Couplings |
|
Feature |
Oil Resistance |
|
Coupling Structure |
Helical Coupling |
|
After-sales Service |
Online Support |
|
Processing |
Forging |
|
Standard or Nonstandard |
Standard |
|
Availability |
Stock |
Products Show
Packaging & Delivery
| Packaging Details: | Plastic bag, Carton |
| Delivery Detail: | Within 3 workingdays after payment |
More Parts Information:
Pos. Part No Qty Parts name Comments
0A. PG200585 [1] Hydraulic Pump ( 9287208 NLA)
0B. PG200513 [1] Hydraulic Pump Reman (REMAN FOR 9285685 OR 9287208)
1. ........ [1] Pump (COMPONENTS ON FOLLOWING PAGE)
3. 9291174 [1] Regulator PUMP XX (COMPONENTS ON SEPARATE PAGE)
4. 9291175 [1] Regulator PUMP 2 (COMPONENTS ON SEPARATE PAGE)
5. 4429488 [1] Line
6. 4293950 [2] Fitting
6A. M800650 [1] Packing (SUB FOR (1) 957366)
7. 4153543 [1] O-Ring
8. 9217993 [1] Pump PILOT (COMPONENTS ON SEPARATE PAGE)
9. 19M8337 [2] Screw M10 X 30 (SUB FOR (1) M341030)
10. 12M6791 [2] Lock Washer 10.200 MM (SUB FOR (1) 984054)
11. 4114402 [2] Washer 10.500 X 22 X 3.200 MM (0.413" X 0.866" X 0.126")
13. 4464407 [1] Coupling (ASSY)
13A. 4627119 [1] Hub
13B. 4702173 [2] Set Screw (SUB FOR (1) 4334899)
13C. 34M7117 [3] Spring Pin 5 X 10 MM
13D. 4627120 [3] Insert
13E. 4627121 [3] Bolt
13F. 4627118 [1] Coupling
16. 37H99 [2] Screw 0.100" X 1/4" (SUB FOR (1) M492564)
17. ........ [1] Serial Number Plate ( 3110122 NLA)
Coupling Information:
The function of the coupling is to connect the two shafts (the driving shaft and the driven shaft) in different mechanisms to make them rotate together and transmit torque. Some couplings also have buffering and vibration reduction.
According to different working conditions, the coupling needs to have the following properties:
(1) Portability. The mobility of the coupling refers to the ability to compensate for the relative displacement of the two rotating components. Factors such as manufacturing and installation errors between connected components, temperature changes during operation, and deformation under load all place requirements on portability. Movable performance compensates or relieves additional loads between shafts, bearings, couplings and other components due to relative displacement between rotating components.
(2) Buffering. For occasions where frequent load starts or working load changes, the coupling needs to have elastic elements for buffering and vibration damping to protect the prime mover and the working machine from being damaged or not damaged.
(3) Safe, reliable, with sufficient strength and service life.
(4) Simple structure, convenient assembly and disassembly and maintenance. Couplings are also called couplings. A mechanical component used to firmly connect the driving shaft and the driven shaft in different mechanisms to rotate together and transmit motion and torque. Sometimes it is also used to connect shafts and other parts
Guangzhou XIEBAGN MACHINERY CO., LIMTED
specialized in:
couplings, rubber mounts, gera parts, hydraulic seals and seal kits for hydraulic hammers, rock breakers, hydraulic excavators,wheel loaders, and JCB badkhoe loaders.
And, Our company also supply:
Engine parts, hydraulic piston pump and hydraulic travel motor, Swing motor assembly and hydraulic component parts, electric parts, etc. Hydraulic hammer breaker parts with piston, cylinder, chisel, through bolt, side bolt, top bush, front head bushing,accumlator, valve, etc.
We always try our best for all our customers and make it better and better. Welcome!
