Hydraulic Pump Coupling Excavator Machine Parts Fits 225CLC

Hydraulic Pump Coupling Quality Excavator Machine Parts Fits 225CLC

Description :

Products Show

Packaging & Delivery

More Parts Information:

Pos. Part No Qty Parts name Comments
1. ........ [1] Housing ( 1027184 NLA)
3. 3063840 [1] Gear
4. 3055594 [1] Shaft
5. ........ [1] Housing (PUMP UNIT) (SEE FOLLOWING PAGE FOR COMPONENTS)
6. 8058352 [1] Gasket
7. 19M7489 [6] Cap Screw M16 X 45
8. 6008X [2] Ball Bearing
9. 962002 [1] Snap Ring
10. 40M7090 [10] Snap Ring
13. 37H99 [2] Screw 0.100" X 1/4"
18. 12H294 [6] Lock Washer 5/8"
20. 4276918 [1] Pump PILOT
21. 19M8337 [2] Screw M10 X 30
22. 12M6791 [2] Lock Washer 10.200 MM
23. 4114402 [2] Washer
27. 4369148 [1] Oil Line
30. 3063842 [1] Gear
31. 3063843 [1] Gear
32. AT152406 [2] Snap Ring SUB FOR 4274552
34. 34M7061 [2] Spring Pin 8 X 20 MM
43. 4310055 [1] Seal
51. 4293950 [2] Fitting
51A. M800650 [1] Packing
59. FYB00000114 [1] Coupling SUB FOR 4416605
59A. ........ [1] Hub
59B. 4702173 [2] Set Screw SUB FOR 4334899
59C. 34M7117 [4] Spring Pin 5 X 10 MM
59D. ........ [4] Insert
59E. 4334894 [4] Bolt
59F. ........ [1] Housing
61. FYB00001633 [1] Gauge SUB FOR 4438059
62. 9743977 [1] Dipstick Tube
63. 9742779 [1] Gasket
64. 19M7647 [2] Screw M8 X 16
68. 4265372 [1] Sensor ENGINE SPEED
69. 4306888 [1] O-Ring
70. 24M7054 [1] Washer 6.400 X 12 X 1.600 MM
71. 19M8553 [1] Screw M6 X 16
86. 4234782 [1] Plug
87. 15M7036 [1] Drain Plug SUB FOR 0309805
88. CH11570 [1] O-Ring
89. 4451036 [1] Seal Kit

Coupling Information:

The function of the coupling is to connect the two shafts (the driving shaft and the driven shaft) in different mechanisms to make them rotate together and transmit torque. Some couplings also have buffering and vibration reduction.
According to different working conditions, the coupling needs to have the following properties:
(1) Portability. The mobility of the coupling refers to the ability to compensate for the relative displacement of the two rotating components. Factors such as manufacturing and installation errors between connected components, temperature changes during operation, and deformation under load all place requirements on portability. Movable performance compensates or relieves additional loads between shafts, bearings, couplings and other components due to relative displacement between rotating components.
(2) Buffering. For occasions where frequent load starts or working load changes, the coupling needs to have elastic elements for buffering and vibration damping to protect the prime mover and the working machine from being damaged or not damaged.
(3) Safe, reliable, with sufficient strength and service life.
(4) Simple structure, convenient assembly and disassembly and maintenance. Couplings are also called couplings. A mechanical component used to firmly connect the driving shaft and the driven shaft in different mechanisms to rotate together and transmit motion and torque. Sometimes it is also used to connect shafts and other parts
